DB-Mark DP26+ 2-in 6-out Active Crossover 2 input 6 output Pro Speaker Management System Controller Product Code: DBMDP26PLUS Brand: dBMark Balanced inputs and 6 balanced outputs on XLRs. Outputs are impedance balanced, and not fully active balanced Fully adjustable crossover filters on all output channels, with slopes from 12dB to 48dB per octave. Linkwitz-Riley, Butterworth, or Bessel curves can be individually selected on the high-pass and low-pass. Each input has 2 dynamic EQs, noise gate, and adjustable compressor. Automatic Gain Control available on input channels. Configurable compressor and peak limiter on every output channel. Delay on all channels, adjustable in milliseconds, metres or feet. Full matrix mixing, route any input to any output. All input and output channels can be individually muted. Channels can be linked for convenience to allow editing of two or more channels at a time 32-bit digital signal processor with 24-bit 96KHz A/D and D/A converters. USB 2.0/3.0, RS485, and Ethernet connections are provided for PC control of multiple devices. Operation possible using the front panel controls, Windows app, or the built-in web interface. 30 user-program presets can be stored into the device and recalled, or backed-up to PC via USB. Password protection for partial or full lock of system settings. LED indicators on all input and output channels for level, mute, compressor, limiter, and peak/clip. 2×24 character dot-matrix blue back-lit LCD display.
